PRIMAX VENUS 4200 Hybrid Solar Inverter 4200W 24V MPPT 2024

PRIMAX VENUS 4200 Hybrid Solar Inverter 4200W 24V MPPT 2024

Rs.155,000.00 Rs.123,999.00

PRIMAX VENUS 4200 Hybrid Solar Inverter 4200W 24V MPPT 2024

Rs.155,000.00 Rs.123,999.00

PRIMAX VENUS 4200 Hybrid Solar Inverter 4200W 24V MPPT 2024










  • Pure Sine wave solar inverter (On/Off Grid)
  • Output Power factor 1.0
  • WIFI & GPRS available for IOS and Android
  • Inverter can run without battery
  • One-key restoration to factory settings
  • Built-in Lithium battery automatic activation
  • Built-in 120A MPPT Solar charge: max 6200W (for 3.6KW/4.2KW), max 6500W (for 6.2KW)
  • High PV input voltage range (60~500V DC)
  • Built-in Anti-dust kit for harsh environment
  • Smart battery charge design for optimize battery life
  • Dual output

    Download PDF



Phase 1-Phase
Maximum PV Input Power 6200W
Rated Output Power 4200W
Maximum Solar Charging Current 120A
GRID-TIE OPERATION
PV Input (DC)
Nominal DC Voltage/Maximum DC Voltage 360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage 60VDC/90VDC
MPPT Voltage Range 60VDC-450VDC
Number of MPPT Trackers/Maximum Input Current 1/18A
GRID OUTPUT(AC)
Nominal Output Voltage 220/230/240VAC
Output Voltage Range 195.5-253VAC
Nominal Output Current 18.2A
Power Factor >0.99
Feed-in Grid Frequency Range 49-51+1Hz
EFFICIENCY
Maximum Conversion Efficiency(DC/AC) 98%
TWO-LOAD OUTPUT POWER
Full Load 4200W
Maximum Main Load 4200W
Maximum Second Load(Battery mode) 1400W
Main Load Cut-Off Voltage 22VDC
Main Load Return Voltage 26VDC
OFF-GRID OPERATION AC INPUT
AC Start-up Voltage/Auto Restart Voltage 120-140VAC/180VAC
Acceptable Input Voltage Range 90-280VAC or 170-280VAC
Maximum AC Input Current 30A
Nominal operating frequency 50/60Hz
Surge Power 8400W
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage 220/230/240VAC
Output Waveform Pure sine wave
Efficiency(DC to AC) 94%
BATTERY & CHARGER
Nominal DC Voltage 24VDC
Maximum Solar Charging Current 120A
Maximum AC Charging Current 100A
GENERAL
PHYSICAL
Dimension, D X W X H(mm) 420*310*110
Cartoon Dimension, D X W X H(mm) 500*410*190
Net Weight(kgs) 8.5
Gross Weight(kgs) 9.5
INTERFACE
Communication Port RS232/WIFI/GPRS/LITHIUM
 BATTERY
